Parameter Setting Operations
3-9 IM 77C01E01-01E
1
2
3
4
5
A
I
3.5 Setting Ethernet Communication Conditions
Set the settings of
parameter to
ON and press
twice.
9
Ethernet setting switch Ethernet setting switch
To return to the Ethernet
Communication Menu screen,
press .
Set the Ethernet setting switch to
ON to enable the new settings.
When the settings have been
updated, the switch is
automatically set back to OFF.
The parameter settings have
been updated.
To return to the Measured Value
screen, hold down .
If you do not operate any key for more
than 5 minutes on the Parameter
screen, the PR300 automatically
returns to the Measured Value screen.
NOTE
● When using Ethernet communication, set the RS-485 communication protocol to Modbus/TCP (see
Section 3.4).
●
To be able to update the Ethernet parameter settings, the Ethernet setting switch must be set to ON.
● It takesabout 20 seconds to update the setting. Ethernet communication cannot be used during this time.
Parameter Setting Types and Ranges
Ethernet communication menu
IP address-1
IP address-2
IP address-3
IP address-4
Subnet mask-1
Subnet mask-2
Subnet mask-3
Subnet mask-4
Default gateway-1
Default gateway-2
Default gateway-3
Default gateway-4
Port number
Ethernet setting switch
Integral
numeric
value
Integral
numeric
value
Integral
numeric
value
Integral
numeric
value
Selection
0 to 255
0 to 255
0 to 255
0 to 255
0 to 255
0 to 255
0 to 255
0 to 255
0 to 255
0 to 255
0 to 255
0 to 255
502, 1024 to 65535
ON
OFF
Menu to shift to the parameters of
Ethernet communication
192
168
1
255
255
255
0
0
0
0
0
502
1
Parameter Symbol Parameter Name
Setting
Type
Setting Range (Details)
Initial Value
(Factory-set
Value)
