48 ANASCAN User’s Guide
TREND PLOT
Function Keys
Trend Plot Setup Screen
The Plot Setup screen allows editing scales and parameters and
combining channels.
Getting Here
Press F1 from the Trend Plot screen. The screen is shown on the next
page.
Key Function
F1 Plot setup. Enter the Plot Setup screen.
F2 Single channel. Display the trend plot for the channel being
edited when you entered the Trend Plot screen.
F3 Combine channels. Display the trend plot for the first group of
combined channels defined on the Plot Setup screen
ESC Return to the screen the trend plot was entered from.
