ANASCAN User’s Guide 21
CHANNEL OVERVIEW
The Channel Overview screen provides an overview of the process
information. It is not password protected and is available at all times for
anyone who wishes to monitor the process variables.
Getting Here
This screen appears automatically after start up.
Options
The Overview screen has four display screens. Use the F6 key to switch
between displays.
1. Four-channel graph display. Each channel includes a range of param-
eters.
Single channel display *
* The single channel display includes the chan-
nel name, setpoint, process variable, alarm
messages, warning and alarm setpoints.
