ANASCAN User’s Guide 25
EDIT
The Edit screen enables you to change the setpoint of the single channel
display you have selected:
The Edit screen uses the same format as the Overview screen, only here
you can move the cursor to change the values. This screen is not
password protected.
The Edit screen performs the same functions as the change setpoint on
the CAS front panel.
Getting Here
Press F1 from the Overview screen. You will enter an Edit screen with
the same display as the screen you were in before pressing F1. The
screen below is an Edit screen for the 16 channel display, and the
additional 17th channel for pulse.
Function Keys
Key Function
PgUp/PgDn Display other channels for editing.
Tab Reach channels of other groups.
ESC Return to Overview screen.
