Chapter 3 Specifications
3-5
„Display Specifications
„Touch Panel Specifications
GP4104G/4105G/4106G/4107G GP4104W/4105W/4106W/4107W
Display Type STN Monochrome LCD
Display Size 3.4"
Resolution 200 x 80 pixels
Dot pitch W0.4 x H0.4 mm [W0.02 x H0.02 in.]
Effective Display Area 79.985 x 31.985 mm
Display Colors
Monochrome Green/Red/Orange
(16 Levels) Monochrome White/Red/Pink
(16 Levels)
Backlight
*1
*1 The backlight burnout detection function is not supported.
Green/Red LED
(User nonreplaceable parts.
Factory replacement required.) White/Red LED
(User nonreplaceable parts.
Factory replacement required.)
Brightness Control 16 Levels (Adjusted with the touch panel)
Contrast Control 8 Levels (Adjusted with the touch panel)
Backlight Service Life
Green: 50,000 hrs. or more, Red
10,000 hrs. or more (each in
continuous operation at 25°C
before backlight brightness
decreases to 50%) White: 50,000 hrs. or more, Red
10,000 hrs. or more (each in
continuous operation at 25°C
before backlight brightness
decreases to 50%)
Language Fonts
*2
*2 Please refer to the GP-Pro EX Reference Manual for details on font types and character codes.
Japanese, ASCII, Chinese (Simplified), Chinese (Traditional),
Korean, Cyrillic, Thai
Character Sizes
Standard font: 8 x 8, 8 x 16, 16 x 16 and 32 x 32 pixel fonts
Stroke font: 6 to 80 pixel fonts
Image font: 8 to 72 pixel fonts
Font Sizes
Standard font: Width can be expanded up to 8 times. Height can be
expanded up to 8 times.
*3
*3 Other font sizes can be set up with the Editor software.
Text 8 X 16 pixels 25 char. x 5 rows
Text 16 X 16 pixels 12 char. x 5 rows
Text 32 X 32 pixels 6 char. x 2 rows
Touch Panel
Type
Resistive Film (analog)
Touch Panel
Resolution
1,024 x 1,024
Touch Panel
Service Life
1,000,000 times or more
