2 edit mode peripherals, 1 gp run mode peripherals -4 – Proface GP4100 - 3.4 Compact HMIs" User Manual
Page 24
Chapter 1 Accessories/System Design
1-7
1.2.2
Edit Mode Peripherals
GP-4100 Series
USB (Type A) Interface
(USB1)
Ethernet Interface
(10BASE-T/100BASE-TX)
Only for GP4104
To an Ethernet Network
USB (mini B) Interface
(USB2)
USB Memory Strage*1
(Commercial type)
USB Port
USB Port
USB Data Transfer Cable
(USB A/mini-B)
ZC9USCBMB1
Personal Computer
(Commercial type) *2
Screen Editor
Software
GP-Pro EX
*1
For supported models, refer to Pro-face’s support site
“Otasuke Pro!” (http://www.pro-face.com/otasuke/).
You can connect to this site by clicking the GP-Pro EX’s [Help (H)] menu-
[Connect to Support Site“Otasuke Pro!” (C)] command.
*2
Certain types and models of PCs cannot be used.
Please refere to GP-Pro EX Reference Manual
for the software's operating environment requirements.
