AFL2-W15A-N270 Panel PC
Page 52
3.3.3 Super IO Configuration
Use the Super IO Configuration menu (BIOS Menu 6) to set or change the
configurations for the FDD controllers, parallel ports and serial ports.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Power Exit
Configure Super I/O Chipset
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Serial Port1 Address
[3F8/IRQ4]
Serial Port2 Address [2F8/IRQ3]
Serial Port3 Address [3E8]
Serial Port3 IRQ [10]
Select RS232/RS422 or RS485 [RS232/RS422]
Allows BIOS to select
Serial Port Base
Addresses
Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
V02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 6: Super IO Configuration
Serial Port1 Address [3F8/IRQ4]
Selects the serial port base address.
Disabled No base address
3F8/IRQ4 D EFAULT
I/O address 3F8 and interrupt address IRQ4
3E8/IRQ4 I/O address 3E8 and interrupt address IRQ4
2E8/IRQ3
I/O address 2E8 and interrupt address IRQ3
Serial Port2 Address [2F8/IRQ3]
Selects the serial port base address.
Disabled
No base address
2F8/IRQ3 D EFAULT
I/O address 2F8 and interrupt address IRQ3
3E8/IRQ4 I/O address 3E8 and interrupt address IRQ4
