AFL2-W15A-N270 Panel PC
Page 7
1.6 Specifications
The technical specifications for the AFL2-W15A-N270 systems are listed in Table 1-2.
SPECIFICATIONS AFL2-W15A-N270/R/1G-R20 AFL2-W15A-N270/PC/1G-R20
LCD Panel 15.6"
Resolution 1366 x 768
Brightness 300
Contrast Ratio 500:1
LCD Colors 16.7 million
Pixel Pitch 0.252 x 0.252
Viewing Angle (H/V) 170/160
Backlight MTBF 50000 hrs. (LED backlight)
Touchscreen R model: 5-wire resistive type (RS-232 interface)
PC model: Projected capacitive type (USB interface)
Mainboard AFLMB2-945GSE-N270
CPU 1.6 GHz Intel® Atom processor N270
Chipset Intel® 945GSE + ICH7M
Memory One 1 GB 667 MHz or 800 MHz DDR2 SO-DIMM preinstalled
(system max. 2 GB)
Ethernet Controller Realtek RTL8111CP PCIe GbE controller with ASF 2.0 support
Watchdog Timer Software programmable supports 1~255 sec. system reset
Audio Realtek ALC888 HD Audio codec
Two 1.5 W internal speakers
Camera 2-megapixel camera with low light function
Storage CF Type II
One 2.5” SATA HDD bay
OSD Function LCD on/off, brightness up/down, volume up/down
Wireless LAN 802.11b/g/n 2T2R module
RFID Reader
(Optional)
EM 125 KHz card reader or
Mifare 13.56 MHz card reader
