AFL2-W15A-N270 Panel PC
Page 18
WARNING!
Take antistatic precautions when working on the internal
components. Some internal components are easily damaged or
destroyed by electrostatic discharge. Take antistatic precautions to
prevent electrostatic discharge.
To access the internal components, the plastic back cover and the internal aluminum
cover of the AFL2-W15A-N270 must be removed. To remove the back cover, unfasten the
retention screws and then lift the cover to remove.
Figure 2-8: Plastic Back Cover Retention Screws
To remove the internal aluminum cover, unfasten the eight retention screws and then lift
the cover to remove.
