AFL2-W15A-N270 Panel PC
Page 19
Figure 2-9: Internal Aluminum Cover Retention Screws
2.7 Jumper Settings
NOTE:
A jumper is a metal bridge used to
close an electrical circuit. It consists of
two or three metal pins and a small
metal clip (often protected by a plastic
cover) that slides over the pins to
connect them. To CLOSE/SHORT a
jumper means connecting the pins of
the jumper with the plastic clip and to OPEN a jumper means removing
the plastic clip from a jumper.
The following jumpers can be found on the motherboard installed in the AFL2-W15A-N270.
Before the AFL2-W15A-N270 is installed, the jumpers must be set in accordance with the
desired configuration. The jumpers on the AFL2-W15A-N270 motherboard are listed in
Table 2-2.
