AFL2-W15A-N270 Panel PC

Page 13

Quantity Item


1

Power cord

4

Screws

1

HDD bracket

1

Touch screen pen

1

Remote Control

1

Utility CD

Table 2-1: Packing List

If any of these items are missing or damaged, contact the distributor or sales

representative immediately.

2.3 Hard Drive Installation

This section outlines the installation of the hard drive in the AFL2-W15A-N270. To install

the hard drive, please follow the steps below:

Step 1:

Unfasten the right plastic side access panel (SATA/CF card/USB dongle access

panel) retention screws and remove the right plastic side access panel

(Figure 2-1).
