AFL2-W15A-N270 Panel PC

Page 12

2.1 Unpack the Panel PC

To unpack the flat panel PC, follow the steps below:

WARNING!

Only remove the protective plastic cover stuck to the front screen after

installation. The plastic layer protects the monitor surface during

installation process.

Step 1:

Carefully cut the tape sealing the box. Only cut deep enough to break the tape.

Step 2:

Open the outside box.

Step 3:

Carefully cut the tape sealing the box. Only cut deep enough to break the tape.

Step 4:

Open the inside box.

Step 5:

Lift the monitor out of the boxes.

Step 6:

Remove the peripheral parts box from the main box.

2.2 Packing List

The AFL2-W15A-N270 flat panel PC is shipped with the following components:

Quantity Item


AFL2-W15A-N270

Power adapter
