AFL-08AH-N270-CR Panel PC
Page 84
A.1 Motherboard Specifications
The system comes with an AFLMB-945GSE-N270-AV-R10 motherboard. The detailed
specifications for the motherboard are listed below.
Specification AFLMB-945GSE-N270-AV-R10
Northbridge Intel® 945GSE
Southbridge Intel® ICH7
Processor 1.6 GHz Intel® Atom™ N270 processor
FSB Speed 533 MHz
Supported Memory One 200-pin 2.0 GB (max.) 533 MHz or 400 MHz DDR2 SDRAM SO-DIMM
(system max. 2.0 GB)
System BIOS AMI BIOS
Hard disk drives Two SATA drives
VGA Integrated in the Intel® 945GSE
LAN Realtek RTL8111CP PCIe GbE Controllers
Expansion Options One PCIe Mini
Super I/O ITE IT8718F
Audio Codec RealTek ALC888
Audio Amplifier NXP TDA1517P
USB Six external USB 2.0 ports
RS-232 Fintek
FAN connector One 4-pin CPU fan connector
A.2 Processor Specifications
The N270 Intel® Atom™ processor specifications are given below.
Parameter Specifications
CPU Speed 1.6 GHz
Bus Speed 533 MHz
L2 Cache Size 512 KB
L2 Cache Speed 1.6 GHz
Manufacturing Technology 45 nm
