AFL-08AH-N270-CR Panel PC
Page 7
1.4 System Specifications
The technical specifications for the AFL-08AH-N270-CR systems are listed in Table 1-1.
Specification AFL-08AH-N270-CR
LCD Size 8.4”
Max. Resolution 800 x 600
Contrast Ratio 600:1
Brightness (cd/m 2 ) 450
LCD Color 262K
Pixel Pitch (H x V) (mm) 0.213 x 0.213
Viewing Angle (H-V) 140 / 120
Backlight MTBF 50,000 hours
SBC Model AFLMB-945GSE-N270-CR-R10
CPU 1.6 GHz Intel® Atom™ N270 processor
GMCH Intel® 945GSE
Memory One 1.0 GB 533 MHz DDR2 SDRAM SO-DIMM pre-installed
(Supports up to 2 GB 533/400 MHz DDR2 SDRAM)
SSD 1 x CF card
Watchdog Timer Software Programmable supports 1 sec. ~ 255 sec. system reset
Audio AMP 1.5 W + AMP 1.5 W (built-in stereo speakers)
Expansion 1 x PCIe mini card (wireless LAN 802.11 b/g module)
Construction Material ABS + PC plastic front frame
Mounting Panel
Wall
Stand
Arm (VESA 75 mm x 75 mm)
Front Panel Color Gray 7539U
Dimensions (W x H x D) (mm) 234 x 184 x 41.09
Temperature Operation: -10ºC ~ 50ºC with CF card
Storage/Transportation: -20ºC ~ 60ºC
Humidity Operation: 30%~70%
Storage/Transportation: 10%~95%
Net weight 0.8 kg
