AFL-08AH-N270-CR Panel PC
Page 86
A.4 Touch Screen Specifications
The AFL-08AH-N270-CR comes with an analog resistive type touch panel. The touch
panel specifications are listed below.
SPECIFICATION AFL-08AH-N270-CR
Model PANJIT 1084403B
Type Analog Resistive Type Touch Panel
Wire Type 4-wire
Viewing Area (mm) 130.75 x 173.38
Active Area (mm) 127.78 x 170.38
Total Transmission 78%
Maximum Voltage DC7V
Connector Type FPC.
Operating Temperature -10°C ~ 50°C
Operating Humidity 20% ~ 90% RH
Storage Temperature -20°C ~ 70°C
Storage Humidity 20% ~ 90% RH
Dimensions 145.5 x 188 x 2.1
