5.3.8 S e ria l P o rt Co n s o le Re d ire c tio n

The Serial Port Console Redirection menu (BIOS Menu 12) allows the console

redirection options to be configured. Console redirection allows users to maintain a

system remotely by re-directing keyboard input and text output through the serial port.

Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.

Advanced

COM1

Console Redirection

[Disabled]

> Console Redirection Settings

COM2

Console Redirection

[Disabled]

> Console Redirection Settings

COM3

Console Redirection

[Disabled]

> Console Redirection Settings


Console Redirection
Enable or Disable



---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.

BIOS Menu 12: Serial Port Console Redirection

 Co n s o le Red ire ctio n [Dis ab led ]

Use Console Redirection option to enable or disable the console redirection function.

Disabled

D

EFAULT

Disabled the console redirection function

Enabled

Enabled the console redirection function

 Term in al Typ e [ANSI]

Use the Terminal Type option to specify the remote terminal type.

VT100

The target terminal type is VT100

VT100+

The target terminal type is VT100+

VT-UTF8

The target terminal type is VT-UTF8

ANSI

D

EFAULT

The target terminal type is ANSI
