ECN-360A-D2550 Em b e d d e d S ys te m

P a g e 50

5.2 Ma in

The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered.

The Main menu gives an overview of the basic system information.

Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.

Main

Advanced

Chipset

Boot

Security Save & Exit

BIOS Information
BIOS Vendor

American Megatrends

Core Version

4.6.5.3 0.16

Compliancy

UEFI 2.3; PI 1.2

Project Version

B239AR10.ROM

Build Date and Time

05/11/2012 11:53:40


System Date

[Mon 07/16/2012]

System Time

[15:10:27]

Access Level

Administrator


Set the Date. Use Tab to
switch between Data
elements.


----------------------

: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.

BIOS Menu 1: Main

 S ys tem Overview

The BIOS Information lists a brief summary of the BIOS. The fields in BIOS Information

cannot be changed. The items shown in the system overview include:

BIOS Vendor: Installed BIOS vendor

Core Version: Current BIOS version

Project Version: the board version

Build Date and Time: Date and time the current BIOS version was made

The System Overview field also has two user configurable fields:

 S ys tem Date [xx/xx/xx]

Use the System Date option to set the system date. Manually enter the day, month and

year.
