ECN-360A-D2550 Em b e d d e d S ys te m

P a g e 56

5.3.5 US B Co n fig u ra tio n

Use the USB Configuration menu (BIOS Menu 7) to read USB configuration information

and configure the USB settings.

Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.

Advanced

USB Configuration

USB Devices:
1 Keyboard


Legacy USB Support

[Enabled]



Enables Legacy USB
support. AUTO option
disables legacy support
if no USB devices are
connected. DISABLE
option will keep USB
devices available only
for EFI applications.

---------------------
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit

Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.

BIOS Menu 7: USB Configuration

 USB Devices

The USB Devices field lists the USB devices that are enabled on the system

 Leg ac y USB Su p p o rt [En ab led ]

Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard

support.

Normally if this option is not enabled, any attached USB mouse or USB keyboard does not

become available until a USB compatible operating system is fully booted with all USB

drivers loaded. When this option is enabled, any attached USB mouse or USB keyboard

can control the system even when there is no USB driver loaded onto the system.

Disabled

Legacy USB support disabled
