TANK-700 Em b e d d e d S ys te m
P a g e 61

IO=3E8h;
IRQ=3, 4, 5,
6, 7, 9, 10,
11, 12
Serial Port I/O port address is 3E8h and the interrupt
address is IRQ3, 4, 5, 6, 7, 9, 10, 11, 12

IO=2E8h;
IRQ=3, 4, 5,
6, 7, 9, 10,
11, 12
Serial Port I/O port address is 2E8h and the interrupt
address is IRQ3, 4, 5, 6, 7, 9, 10, 11, 12
 Device Mo d e [No rm al]
Use the Device Mode option to enable or disable the serial port.

Normal D EFAULT Sets the serial port mode to normal.

RS422/485 Enables serial port RS-422/485 support.
4.3.7 S u p e r IO Co n fig u ra tio n
Use the Super IO Configuration menu (BIOS Menu 10) to set or change the
configurations for the serial ports.
Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.
Advanced
Super IO Configuration
Super IO Chip
Finteck F81866
> Serial Port 1 Configuration
> Serial Port 2 Configuration
> Serial Port 3 Configuration
> Serial Port 4 Configuration
> Serial Port 5 Configuration
> Serial Port 6 Configuration
Set Parameters of Serial
Port 1 (COMA)
---------------------
: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1
General Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.10.1208. Copyright (C) 2010 American Megatrends, Inc.
BIOS Menu 10: Super IO Configuration
