TANK-700 Em b e d d e d S ys te m
P a g e 3
1.3 Fe a tu re s
The TANK-700 features are listed below:
 Intel® 32nm mobile Core™ i7/i5/i3 or Celeron® processor
 Intel® HD graphics supports H.264/AVC-MPEG2/VC1, DirectX 10.1 and
OpenGL 3.0
 2.0 GB of DDR3 memory preinstalled
 Dual Combo Gigabit Ethernet ports (SFP Fiber/RJ-45)
 8-Channel audio/video capture support
 Dual display via VGA and HDMI
 Dual-band 2.4/5 GHz 802.11a/b/g/n 3T3R MIMO Wi-Fi for high speed
wireless transmission
 Redundant dual DC input (9V~36V)
 CAN-bus interface with isolation
 Two USB 3.0 ports
 Four USB 2.0 ports
 Two SATA 6Gb/s ports
 Eight COM ports (four with isolation)
 Extended temperature fanless design supports -20 °C~70°C
1.4 Te c h n ic a l S p e c ific a tio n s
The TANK-700 technical specifications are listed in Table 1-2.
S p e c ific a tio n s
S ys te m
CP U Intel® 32nm mobile Core™ i7/i5/i3 or Celeron® processor
Ch ip s e t Intel® QM67
Me m o ry 1 x 204-pin 1066/1333 MHz dual-channel DDR3 SDRAM SO-DIMM
slot (system max. 10 GB)
2.0 GB of DDR3 memory preinstalled
Eth e rn e t Co n tro lle r Intel® 82579 PHY with Intel® AMT 7.0 support
Intel® 82583V Ethernet controller
