TANK-700 Em b e d d e d S ys te m
P a g e 28
Pin Description Pin Description
1 HDMI_DATA2 2 GND
3 HDMI_DATA2# 4 HDMI_DATA1
5 GND 6 HDMI_DATA1#
7 HDMI_DATA0 8 GND
9 HDMI_DATA0# 10 HDMI_CLK
11 GND 12 HDMI_CLK#
13 N/C 14 N/C
15 HDMI_SCL 16 HDMI_SDA
17 GND 18 +5V
19 HDMI_HPD 20 HDMI_GND
21 HDMI_GND 22 HDMI_GND
23 HDMI_GND
Table 3-2: HDMI Connector Pinouts
3.9.8 LAN Co n n e c to rs
CN La b e l: LAN
CN Typ e : RJ-45
CN Lo c a tio n : See Figure 1-3
CN P in o u ts : See Table 3-3
The LAN connectors allow connection to an external network.
S te p 1: Locate the RJ-45 connectors. The locations of the RJ-45 connectors are
shown in Figure 1-3.
S te p 2: Align the connectors. Align the RJ-45 connector on the LAN cable with one of
the RJ-45 connectors on the TANK-700. See Figure 3-17.
