TANK-700 Em b e d d e d S ys te m
P a g e 4
S p e c ific a tio n s
I/O a n d In d ic a to rs
Eth e rn e t 2 x Combo (SFP Fiber/RJ-45) Gigabit LAN
RS -232 4 x DB-9 serial ports on rear panel
2 x RJ-45 serial ports with isolation on front panel
RS -422/RS -485 2 x RJ-45 serial ports with isolation on front panel
US B In te rfa c e s 2 x USB 3.0 ports on front panel
4 x USB 2.0 ports on rear panel
Dis p la y 1 x VGA port (supports resolution up to 2048 x 1536 @ 75Hz)
1 x HDMI port (supports resolution up to 1920 x 1200 @ 60Hz)
Au d io Co n n e c to r 1 x Line-out port
1 x Mic-in port
CAN-b u s 1 x Phoenix terminal block on front panel
Au d io /Vid e o Ca p tu re Optional 4-channel audio/video input PCIe Mini card (up to two
cards)
Dig ita l I/O 1 x DIO port (8 bits)
LED In d ic a to rs AT power mode LED
ATX power mode LED
CAN-bus LED
CPU temperature alert LED
HDD LED
LAN 1 LED
LAN 2 LED
Power 1 LED
Power 2 LED
SFP Fiber 1 LED
SFP Fiber 2 LED
Wireless LED
S to ra g e
S ATA 2 x SATA 6Gb/s with 2.5” HDD/SSD support
