IMBA-H610 ATX Motherboard
Page 74
ƒ L2 Cache: Lists the amount of storage space on the L2 cache.
ƒ L3 Cache: Lists the amount of storage space on the L3 cache.
5.3.4 SATA Configuration
Use the SATA Configuration menu (BIOS Menu 7) to change and/or set the
configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
SATA Configuration
SATA Mode [IDE Mode]
Serial-ATA Controller 0 [Compatible]
Serial-ATA Controller 1 [Enhanced]
SATA Port0
Not Present
SATA Port1 Not Present
SATA Port4
Not Present
SATA Port5
Not Present
(1) IDE Mode. (2) AHCI
Mode. (3) RAID Mode.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+ - Change Opt.
F1 General
Help
F2 Previous Values
F3 Optimized Defaults
F4 Save & Exit
ESC Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 7: SATA Configuration
Î SATA Mode [IDE Mode]
Use the SATA Mode option to configure SATA devices as normal IDE devices.
Î
Disable Disables SATA devices.
Î
IDE Mode D EFAULT Configures SATA devices as normal IDE device.
Î
AHCI Mode Configures SATA devices as AHCI device.
Î Serial-ATA Controller 0 [Compatible]
Use the Serial-ATA Controller 0 option to configure the serial ATA controller 0.
Î Disabled Disables the on-board ATA controller.
