3.1.2 Peripheral Interface Connectors
The table below lists all the connectors on the board.
Connector Type Label
+12V ATX power supply connector 4-pin Molex CPU12V1
ATX Power connector 24-pin ATX ATX1
Battery connector 2-pin wafer BT2
Battery holder CR2032 battery holder BAT1
DDR3 DIMM slots DDR3 DIMM slot CHA_DIMM1
CHB_DIMM1
Digital I/O connector 10-pin header DIO1
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connector (system 1) 3-pin wafer SYS_FAN1
Fan connector (system 2) 3-pin wafer SYS_FAN2
Front panel audio connector 10-pin header FP_AUDIO1
Front panel connector 14-pin header F_PANEL1
I2C connector 4-pin wafer I2C_1
Parallel port connector 26-pin box header LPT1
PCI slots PCI slots PCI1, PCI2, PCI3,
PCI4
PCIe x1 slots PCIe x1 slot PCIEX1_1,
PCIEX1_2
PCIe x16 slot PCIe x16 slot PCIEX16_1
SATA 3Gb/s drive connector 14-pin SATA connector SATA12, SATA56
Serial port, RS-422/485 4-pin wafer COM4
Serial ports, RS-232 10-pin box header COM3, COM5,
COM6
SMBus connector 4-pin wafer SMBUS_1
SPI ROM connector 8-pin header JSPI1
