IMBA-H610 ATX Motherboard
Page 17
Connector Type Label
TPM connector 20-pin header TPM1
USB connectors 8-pin header USB2, USB3,
USB4
Table 3-1: Peripheral Interface Connectors
3.1.3 External Interface Panel Connectors
The table below lists the connectors on the external I/O panel.
Connector Type Label
Audio connector Audio jack AUDIO_CV1
Ethernet and USB 2.0 ports RJ-45, USB LAN1_USB01_1,
LAN2_USB23_1
Keyboard and mouse connector Dual PS/2 KB_MS2
Serial port connectors 9-pin male DB-9 COM1
VGA and DVI connector 15-pin female,
24-pin header
VIDEO1
Table 3-2: Rear Panel Connectors
3.2 Internal Peripheral Connectors
The section describes all of the connectors on the IMBA-H610.
3.2.1 12V Power Connector
CN Label: CPU12V1
CN Type: 4-pin Molex
CN Location: See Figure 3-2
CN Pinouts: See Table 3-3
The connector supports the 12V power supply.
