KINO-9652 Mini-ITX SBC

Page 68

5 GROUND

(GND)

6

DATA SET READY (DSR)

7 REQUEST

TO

SEND

(RTS)

8

CLEAR TO SEND (CTS)

9 RING

INDICATOR

(RI)

Table 4-23: External Serial Port Pinouts

4.3.6 USB Connector

CN Label:

LAN1_USB1 and LAN2_USB2

CN Type:

USB port

CN Location: See

Figure 4-18

CN Pinouts: See

Table 4-24

USB devices can be connected directly to the USB connectors on the rear panel.

PIN NO.

DESCRIPTION

PIN NO.

DESCRIPTION

1 VCC

5 VCC

2 USBD0-

6 USBD1-

3 USBD0+

7 USBD1+

4 GND

8 GND

Table 4-24: External USB Connector Pinouts
