KINO-9652 Mini-ITX SBC
Page 78
5.3.3 DIMM Installation
WARNING:
Only DDR2 memory module can be installed on the KINO-9652. Do not
install DDR memory modules. If a DDR memory module is installed on
the KINO-9652, the KINO-9652 may be irreparably damaged. Please
make sure the purchased DIMM complies with the memory
specifications of the KINO-9652. DIMM specifications compliant with
the KINO-9652 are listed in Chapter 2.
CAUTION:
The DIMM1 socket must be installed with one DDR2 DIMM to enable
the KINO-9652 to boot-up properly.
To install a DIMM into a DIMM socket, please follow the steps below and refer to
Figure 5-6.
