KINO-9652 Mini-ITX SBC
Page 88
unit, the cooling fan of a power supply can also help generate airflow through the board
surface.
NOTE:
IEI has a wide range of backplanes available. Please contact your
KINO-9652 vendor, reseller or an IEI sales representative at
[email protected] or visit the IEI website ( http://www.ieiworld.com.tw )
to find out more about the available chassis.
5.5.2 Motherboard Installation
To install the KINO-9652 motherboard into the chassis, please refer to the reference
material that came with the chassis.
5.6 Internal Peripheral Device Connections
5.6.1 Peripheral Device Cables
The cables listed in Table 5-8 are shipped with the KINO-9652.
Quantity Type
1 IDE cable
1 RS-232/422/485 cable
2 SATA drive cables
1 SATA drive power cable
Table 5-8: IEI Provided Cables
Optional cables are listed below:
USB cable (dual port)
