KINO-9652 Mini-ITX SBC
Page 20
Specification Ultra ATA/100 Ultra ATA/66 Ultra ATA/33
PIO Mode 0 – 4 0 – 4 0 – 4
PIO Max Transfer Rate 16.6 MB/s 16.6 MB/s 16.6 MB/s
DMA/UDMA designation UDMA 3 - 4 UDMA 3 – 4 UDMA 2
DMA/UDMA Max
Transfer
100 MB/s 66 MB/s 33 MB/s
Controller Interface 5V 5V 5V
Table 2-2: Supported HDD Specifications
2.6.5 Intel
®
ICH8ME Low Pin Count (LPC) Interface
The ICH8ME LPC interface complies with the LPC 1.1 specifications. The LPC bus from
the ICH7 is connected to the following components:
Super I/O chipset
Trusted Platform Module (TPM) connector
2.6.6 Intel
®
ICH8ME PCI Interface
The PCI interface on the ICH8ME is compliant with the PCI Revision 2.3 implementation.
Some of the features of the PCI interface are listed below.
PCI Revision 2.3 compliant
33 MHz
5V tolerant PCI signals (except PME#)
Integrated PCI arbiter supports up to seven PCI bus masters
The PCI bus is interfaced to one PCI slot of the KINO-9652 and supports one expansion
PCI card.
