Page 117

KINO-9652 Mini-ITX SBC

Page 95

USB combo connector is shown in Chapter 3.

Step 2:

Insert an RJ-45 plug.

Insert the RJ-45 plug of a LAN into the RJ-45 receptacle

on the external peripheral interface. See Figure 5-19.

Step 3:

Insert a USB Series "A" plug.

Insert the USB Series "A" plug of a device into

the USB Series "A" receptacle on the external peripheral interface. See Figure

Step 0:

Figure 5-19: RJ-45 Ethernet Connector

5.7.3 VGA Monitor Connection

The KINO-9652 has a single female DB-15 connector on the external peripheral interface

panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor

to the KINO-9652, please follow the instructions below.

Step 1:

Locate the female DB-15 connector. The location of the female DB-15

connector is shown in Chapter 3.

Step 2:

Align the VGA connector. Align the male DB-15 connector on the VGA screen
