Messages in ecg monitoring mode – ZOLL AED Pro Rev J User Manual
Page 72
C
HAPTER
5
ECG M
ONITORING
M
ODE
5–8
www.zoll.com
9650-0350-01 Rev. J
Messages in ECG Monitoring Mode
The following voice prompts and text messages can occur while using the unit for ECG
monitoring:
Message
Description
CHECK PATIENT
ECG monitoring detected a shockable rhythm or low
heart rate. Evaluate the status of the patient.
PLUG IN DEFIB CABLE
The unit detected a shockable rhythm while monitoring
the patient with ECG electrodes.
An ECG cable was plugged in, but the unit is not
configured for ECG monitoring.
Plug in the defibrillation cable.
CHECK ECG ELECTRODES
Ensure that the ECG electrodes are properly attached
to the patient and that the cable is plugged into the unit.
CHECK DEFIB PADS
Ensure that the defibrillation electrode pads are
properly attached to the patient and that the cable is
plugged into the unit.
ATTACH DEFIB PADS TO PATIENT’S
BARE CHEST
The unit does not detect attachment of the defibrillation
electrode pads to the patient.
Attach defibrillation pads to the patient.
