EZCT-2000C USER’S MANUAL REV 1
86
c. The following screen will be displayed:
Use the keypad to enter a test note and press the [ENTER] key.
d. The following confirmation screen will be displayed showing the test parameters (the
screen will vary depending on which test is being performed as defined in the test plan):
Press the [START] key to begin the test.
e. The EZCT-2000C will start performing the test per the test plan parameters. When the
test has finished, the following screen will be displayed:
Press any key to continue.
f. The following screen will be displayed:
Press the [1] key (YES) if you would like to print the test results.
Press the
[2]
key (NO) if you do not want to print the test results.
print test results?
1. YES
2. NO
ANY KEY TO CONTINUE
V
x
=63.4 V
H
=0.3174
I=0.0324 RAT=+199.95
TEST 1 parameters:
50V
0.2A x1-x2
"START" to begin
ENTER TEST 1 NOTE:
_
↑↓
to position
"ENTER" TO ACCEPT
