Vanguard EZCT-2000C Plus - Manual (Page 56)

EZCT-2000C USER’S MANUAL REV 1
52
3.4.4. Printing a Directory of Test Records Stored in the EZCT-2000C’s Memory
You can print a directory of all the test records stored in the EZCT-2000C’s Flash EEPROM using
the steps below:
a. Start from the “START-UP” menu:
Press the
[2]
key (SETUP).
b. The following screen will be displayed:
Press the
[3]
key (RECORD DIRECTORY).
c. The following screen will be displayed:
NOTE
The above screen will be displayed only if a USB Flash drive is NOT connected
to the EZCT-2000C’s USB Flash drive port. If a USB Flash drive is connected,
the following screen will be displayed:
Press the
[1]
key (INTERNAL DIRECTORY). The following screen will be
displayed:
1. INTERNAL DIRECTORY
2. THUMB DRIVE DIR
PRINT DIRECTORY
1.
FULL DIRECTORY
2. SHORT DIRECTORY
1. RECORD ID
2. PRINT RECORD
3. RECORD DIRECTORY
4. SAVE/RESTORE RECORD
5. ERASE RECORD
6. NEXT PAGE
1. RUN TEST 04/17/13
2. SETUP 10:15:55
3. TEST PLANS
4. DIAGNOSTICS
5. CURRENT SOURCE
