EZCT-2000C USER’S MANUAL REV 1
60
3.4.7. Erasing Test Records From the Flash EEPROM
You can erase individual or all test records stored in the EZCT-2000C’s Flash EEPROM. To erase
a test record:
a. Start from the “START-UP” menu:
Press the
[2]
key (SETUP).
b. The following screen will be displayed:
Press the
[5]
key (ERASE RECORD).
c. The following screen will be displayed:
NOTE
The above screen will be displayed only if a USB Flash drive is NOT connected
to the EZCT-2000C’s USB Flash drive port. If a USB Flash drive is connected,
the following screen will be displayed:
Press the
[1]
key (ERASE INTERNAL REC). The following screen will be
displayed:
1. ERASE INTERNAL REC
2. ERASE THUMB DRV REC
ERASE RECORD
1. ERASE SINGLE REC.
2. ERASE ALL RECORDS
"STOP" TO EXIT
1. RECORD ID
2. PRINT RECORD
3. RECORD DIRECTORY
4. SAVE/RESTORE RECORD
5. ERASE RECORD
6. NEXT PAGE
1. RUN TEST 04/18/13
2. SETUP 10:14:25
3. TEST PLANS
4. DIAGNOSTICS
5. CURRENT SOURCE
