REV 1 EZCT-2000C USER’S MANUAL
99
4.5 Printing Raw Memory Buffer Data
You can print the raw data from the EZCT-2000C’s memory buffer for diagnostic purposes. This
will print a table of current and voltage values stored in the unit’s working memory. To print the
raw buffer data:
a. Start from the “START-UP” menu:
Press the [2] key (SETUP).
b. The following screen will be displayed:
Press the [6] key (NEXT PAGE).
c. The following screen will be displayed:
Press the [5] key (PRINT RAW DATA). The raw buffer data will be printed and you will be
returned to the “START-UP” menu.
1. SET TIME
2. SET LANGUAGE
3. BURIED CT IN DELTA
4. KNEE POINT MARKER
5. PRINT RAW DATA
6. DISABLE H-VTG CHECK
1. RECORD ID
2. PRINT RECORD
3. RECORD DIRECTORY
4. SAVE/RES RECORD
5. ERASE RECORD
6. NEXT PAGE
1. RUN TEST 05/02/13
2. SETUP 15:14:25
3. TEST PLANS
4. DIAGNOSTICS
5. CURRENT SOURCE
