Vanguard EZCT-2000C Plus User Manual
Page 36
EZCT-2000C USER’S MANUAL
REV 1
32
3.3.3. Performing a CT Burden Test (EZCT-2000C Plus Only)
The CT burden test verifies the actual CT burden before putting the CT in service. The CT’s
secondary burden is measured by injecting a 1A or 5A test current into the load. To perform a
CT burden test:
a. Make connections per the figure below:
NOTE
This test requires the X1 and X2 cables to be connected to the CT load burden.
