Vanguard EZCT-2000C Plus User Manual
Page 42
EZCT-2000C USER’S MANUAL
REV 1
38
b. Start from the “START-UP” menu:
Press the
[1]
key (RUN TEST).
c. The following screen will be displayed:
Press the
[7]
key (INSULATION TST ONLY)
d. The following screen will be displayed:
Use the alpha-numeric keypad to enter a test note and then press the
[ENTER]
key.
e. The following screen will be displayed:
Select the test voltage by pressing either the
[1]
key (500V) or the
[2]
key (1000V).
INS RES TEST VOLTAGE:
1.
500V
2.
1000V
ENTER TEST 1 NOTE:
_
↑↓
to position
"ENTER" TO ACCEPT
1.
Res, excit & ratio
2.
excitation & ratio
3.
excitation only
4.
ratio only
5.
resistance & excit
6.
burden test only
7.
insulation tst only
1.
RUN TEST 04/17/13
2.
SETUP 07:11:13
3.
TEST PLANS
4.
DIAGNOSTICS
5.
CURRENT SOURCE
