EZCT-2000C USER’S MANUAL REV 1
24
i. The following screen will be displayed:
Type the burden value using the keypad and then press the [ENTER] key.
j. The following screen will be displayed:
Type the Cos ϕ value using the keypad and then press the [ENTER] key.
k. The following screen will be displayed:
Select the rated secondary current by pressing the [1] key (5A) or [2] key (1A).
l. The following screen will be displayed showing a summary of the test parameters:
Press the
[START]
key to start the test.
TEST 1 parameters:
300V
1.0A x1-x2
"START" to begin
rated secondary cur:
1. 5A
2. 1A
ENTER cos
ϕ
:
(0.00 - 1.00)
0.0
ENTER BURDEN VA:
(500.0 max)
0.0
