Operator's Manual

S

EQUENCE

D

ISPLAY

M

ODES

The instrument gives you a choice of five ways to display your segments:

l

Adjacent

l

Waterfall (cascaded)

l

Mosaic (tiled)

l

Overlay

l

Perspective

NOTE: some display modes have limitations on the number of segments that can be shown at one time.
