67
6.4 FS-11WM-100 (Single Slider), FS-12WM-100 (Double Slider)
4.5
195
45
205
160
118
90
Home
10
70
ME
71
35
134
71.5
107
21
8 110
A
D
10
SE
ME
20 15
70
15 20
C 12
52
B
100
8 45
21
103
T-slot
28
67
20.2±0.2
10.2±0.2
70
20 15 15 20
11WM (Single Slider) 12WM (Double Slider)
M8, Depth 14
T-slot Dimension
Cable Joint Connector
SE: Stroke end
ME: Mechanical end
M8, Depth 14
Free Slider Driving Slider
*1 The number in the brackets is the dimension for 12WM.
70 (140 *1)
(300)
FS-11WM-100 (Single Slider)
Stroke 300 400 600 800 1000 1500 2000 2500
A 661 761 961 1161 1361 1861 2361 2861
B 490 590 790 990 1190 1690 2190 2690
C 300 400 600 800 1000 1500 2000 2500
D 370 470 670 870 1070 1570 2070 2570
Weight
[kg]
8.7 9.3 10.5 11.7 12.9 15.9 18.9 21.9
FS-12WM-100 (Double Slider)
Stroke 300 400 500 600 700 800 900 1000
A 624 724 824 924 1024 1124 1224 1324
B 608 708 808 908 1008 1108 1208 1308
C 340 440 540 640 740 840 940 1040
D 460 560 660 760 860 960 1060 1160
Weight
[kg]
3.1 3.5 3.9 4.3 4.8 5.1 5.5 5.9
