59
10) Insert the replacement motor while matching the position (angle) of the alignment marks, and then
attach the motor.
(Use a hexagon wrench with the distance to the opposite side of 2mm.)
11) Attach the motor cover.
(Use a hexagon wrench with the distance to the opposite side of 2.5mm.)
Replacement
Motor
Check the position (angle) of
the alignment marks.
Motor Cover
