Apple MacBook Pro 17-inch (original, Core 2 Duo, 2.4GHz, Late 2007 CTO, Early 2008, and Late 2008) User Manual
Page 41
MacBook Pro 17-inch (original, Core 2 Duo, 2.4/2.6GHz, 2008) Take Apart — Keyboard
41
Use the black stick to defeat the adhesive at the edge so that the film can be peeled back to
12.
access the bend tabs.
Important: When peeling, use care at perforations, notches and narrow parts to avoid
ripping the film.
Peel back the film to access the bend-tabs.
13.
Note: Both films are peeled back here to show
tab location, but you should work on one side at a time.
Note: There are four bend-tabs in the MacBook Pro (17-inch and 17-inch Core Duo) and six
bend-tabs in the MacBook Pro (17-inch 2.4GHz and Early 2008).
