Apple MacBook Pro 17-inch (original, Core 2 Duo, 2.4GHz, Late 2007 CTO, Early 2008, and Late 2008) User Manual
Page 106
MacBook Pro 17-inch (original, Core 2 Duo, 2.4/2.6GHz, 2008) Take Apart — Left I/O Board
106
The ExpressCard cage assembly is attached to the left I/O board. Peel back the Mylar that
5.
covers the top two screws and remove all four screws.
(b) The MacBook Pro (17-inch 2.4GHz and Early 2008 models) will have a black Mylar film
underneath the screws (unlike Kapton below), so no need to remove the film. Just remove
the four pocket screws.
