Set Up Your System 3
Agilent E6474A User’s Guide 39
Phone connection using a USB port
Some phones can be connected to your system using USB
interface cables. When these types of phones are connected to
your system, your PC should automatically detect the new USB
device.
The USB drivers used by these phones may require custom
installation processes. Follow the phone manufacturers
instructions for configuring USB phone connections.
External antennas
The following phone interface kits include antenna adapters. If
your system includes one of the phone interface kits listed in
Table 1 , follow these steps:
1 Connect the antenna adapter to the phone.
2 Connect the antenna extender cable (E6473-60105) to the
appropriate adapter, if necessary. (Two adapters are
included with the antenna kit). The antenna extender cable
connectors are both FME female type.
3 Connect the antenna to the extender cable.
4 Mount the antennas on the roof of the vehicle, with at least
18” (approx. 46 cm) between antennas.
Table 1 Adapters used in kits
Phone interface kit part
number Use with phone(s) Adapter part number Adapter type
E6473-803 QCP 860, 1960, and 2760 E7483-60002 TNC female
E6473-830 Nokia 61xx E7484-60023 FME male
Phone antenna kit part
number Use with frequency bands TNC male to FME male
adapter part number FME male to FME male
Adapter part number
E6473-898 900/1800 MHz E6473-60101 E6473-60102
E6473-899 800/1900 MHz E6473-60101 E6473-60102
