Set Up Your System 3
Agilent E6474A User’s Guide 27
How to connect the E6473B hub
Follow these instructions.
NOTE
Do not connect the E6473B High Speed Direct Connect Hub until you have
installed the E6474A software. Refer to
“Install the E6474A software." on
page 17.
Do this Notes
1 Connect the E6473B hub to a suitable power
source.
Refer to “How to power your
E6473B hub" on page 28.
2 Connect the E6473B hub to the USB port of
your PC.
Refer to Figure 2 .
Figure 2 USB connection between the E6473B hub and your PC.
3 Follow the hardware installation wizard that
starts automatically when you connected the
E6473B hub.
4 Select ‘Search for a suitable driver’.
5 Select ‘Specify location’.
6 Follow the installation instructions.
