Agilent E6474A User’s Guide
B
Connection Panels and LED Indicators
Table 12
Agilent High Speed Direct Connect GPS/DR rear panel
descriptions (see
Figure 64
Agilent High Speed Direct connect GPS/DR rear panel
Reference
Name
Description or Cable Connection
RS232/1PPS
Serial Port and GPS 1PPS
Connects to the PC serial port for GPS data. Overrides the USB port on
the front panel.
Pwr In
Power Input
Used to connects to power supply when the unit is in the rack.
