28 Agilent E6474A User’s Guide
3 Set Up Your System
How to power your E6473B hub
The E6473B hub can be powered from any of these sources.
Power the E6473B hub from the in-vehicle lighter socket
The E6473B hub (option 015) is supplied with a lighter power
cable. The E6473B hub is connected directly to the in-vehicle
lighter socket. Refer to
Figure 3 on page 29.
7 Select the drivers that were added to your PC
when you installed the E6474A software.
These can be found in:
C:\Program Files\Agilent Technologies\
Shared\Drivers\Edgeport\E6473B
Do not use any other drivers.
8 Accept all the installation options listed by the
installation wizard.
Select ‘yes’ for any digital
signature dialogs.
9 The installation process is repeated for each
added port.
10 Restart your PC.
Do this Notes
Powering the E6473B hub Refer to
Power from the in-vehicle lighter socket using the in-vehicle
lighter cable (E6473-90004) (option 015). page 28
Power from the in-vehicle chassis (E6473-60224) connected
directly to the vehicle ignition system (option 021). page 29
Power from a battery (E6473-60008) connection using the
in-building chassis (E6473-60225) (option 022). page 30
