Set Up Your System 3
Agilent E6474A User’s Guide 33
Verifying installation using the Configuration Utility
To verify the driver installation:
Figure 7 Configuration Utility
Test the ports using the Test Ports button:
Do this Notes
1 Connect and switch on the E6473B hub.
2 Select Start > Programs > Agilent Technologies >
Configuration Utility.
3 Select the General tab.
4 Expand the device tree so that you can see all six ports. Refer to Figure 7 .
NOTE
This test uses an internal loopback to test the ports. Devices that generate
data without being polled (for example a GPS receiver or certain phones)
can cause this test to fail. You must unplug all devices before testing the
ports.
