Get Assistance, if You Need It
Table 3
Signal Generator Uplink Settings
Preparing the software
1 Start the E6474A software.
2 Refer to
on page 81, and perform the
procedure, if you have not already done so.
3 Click Log > Start Live Mode.
4 Open the Spectrum Analyzer view and maximize the view.
5 Connect the signal generator output to the RF input of the
receiver.
6 Turn on the signal generator.
7 Set the measurement software as follows:
Band: Uplink
Frequency: Refer to
Table 3
on page 108.
Span: 1 MHz
Averaging: Running
Averages: 32
You should see a signal trace showing a single spectral peak in
the middle of the display, as shown in
Figure 51
on page 109.
Model
Frequency and Power Setting
GSM1900, TDMA, cdma2000 and CDMA PCS
band systems
1879 MHz at –60 dBm
GSM DCS1800 band systems
1748 MHz at –60 dBm
GSM900 band systems
898 MHz at –60 dBm
Cellular CDMA and TDMA band systems
837 MHz at -60 dBm
VHUTÃ@%#$$8Ã rprvr
1950 MHz at –60 dBm
