Ronan X76CTM User Manual
Page 30
X76CTM 9 PIN AND 25 PIN
CABLE ASSEMBLIES
TO HOST RS232 CABLE
5
1
2
3
4
HOST
DE9S
NU
2
2
3
3
5
5
X76CTM
6282-6PG-3XX
3
PINS
13
THRU
1
PINS
25
THRU
14
7
2
3
NU
2
3
5
1
2
X76CTM
6282-6PG-3XX
HOST
DE25P
4
1
6
5
4
3
2
1
6282-6PG-3XX
PIN LOCATION
VIEW FROM
WIRING SIDE
DE25P
PIN LOCATION
VIEW FROM
WIRING SIDE
9 PIN CONNECTOR CABLE ASSEMBLY
25 PIN CONNECTOR CABLE ASSEMBLY
NOTE: Cable length per customer order.
Maximum length 25 ft.
NOTE: Cable length per customer order.
Maximum length 25 ft.
29
9 Pin Cable Assembly
25 Pin Cable Assembly
Item Model No.
Description
1
9536
Cable
2
6282-6PG-3XX
Connector
3
DE9S
Connector, 9 Pin (Female)
4
DDM090003BSKI Back Shell
5
DB110963-1
Cover
Item Model No.
Description
1
9536
Cable
2
6282-6PG-3XX
Connector
3
745496-2
Connector, 25 Pin IDE (Male)
4
745173-3I
Shell with Hardware
